The ideal pellet store
Storage and transport solutions for Windhager pellet boilers

The ideal pellet store

Requirements

The ideal pellet store is dry, offers sufficient room for a year's supply of pellets and is located on an exterior wall. A fire protection door ensures maximum safety.

Storage room with masonry walls

The lorries that deliver your year's supply of pellets can blow them into the storage room from a distance of up to 30 metres. Ideally, your pellet store will be on an exterior wall. It does not need to be right next to the boiler room. Thanks to Windhager's innovative, dust-free suction system, hallways and rooms can be bridged with no problem.



Benefits of the 8-probe suction solution:

  • Cost and time savings for storage room sloping floors*
  • At least 1/3 more space in the storage room
  • The position of the storage room is independent of that of the boiler room
  • Up to 8 removal probes make the system incredibly reliable
  • Patented, completely maintenance-free system
  • Possible to employ two separate storage rooms

Pellet rules of thumb

Storage room Energy content
650 kg pellets = 1 m³ storage volume 1 kg pellets = 4.9 kWh
Store room dimensions without inclined supports in room = building heat load in kW x 0.75 = annual storage room requirement in m³ 2 kg pellets = 1 l of EL heating oil = 1 m³ natural gas
Store room dimensions with inclined supports in room = building heat load in kW x 0.9 = annual storage room requirement in m³ 3 m³ pellets = 1,000 l of EL heating oil = 1,000 m³ natural gas

Customised pellet suction systems

  1 probe 3 probes 8 probes
Configuration recommendation Square storage room with masonry walls, up to 4 m² Rectangular storage room with masonry walls, up to 6 m² Storage room with masonry walls, at least 4 m², 2 separate storage areas (zones) | Special storage room configurations: e.g. L-shaped
Inclined floor Often a good idea Often a good idea Not usually necessary
Safety function Automatic, agitation Automatic, "Flushing and changing over" Automatic, "Flushing and changing over"
Reliable suction up to 25m 25m 25m
Pellet store dimensions Heat load in kW x 0.9 = storage room volume in m³ Heat load in kW x 0.9 = storage room volume in m³ Heat load in kW x 0.75 = storage room volume in m³



Modular sheet steel sloping floor

The modular and cost-effective solution for a warehouse-mounted sloping floor consists of only three basic elements:

  1. Vertical support 0.5 m
  2. Cover plate 0.5 m
  3. Cover plate for extension to 1 m sloping surfaces

Optional: Front cover plates 0.5 m and 1 m



The advantages:

  • Very easy to install – arrange them, screw them into place, and you're done!
  • Custom-fit sloping floor solution for all storage room sizes
  • Simple and self-explanatory construction with only three basic elements
  • Galvanised steel sheet ensures easy sliding of pellets and a long service life
  • Tested stability up to room height of 3 metres
  • Standard cut-out for feed-through of suction pipes

Sheet steel tank - SBT

The storage alternative for damp rooms

A sheet steel tank is suited for pellet storage in damp storage rooms and can be set up directly in the boiler room as it is made entirely of galvanised sheet steel.



The advantages:

  • Flexible adaptation to circumstances* (22 types and up to approx. 10 Meter³)
  • Can be installed directly in the boiler room (maintain legal specifications and distances)
  • High stability and mechanical strength
  • Ideal for damp installation rooms

Fabric tank - get speed

The storage alternative for damp rooms

A fabric tank is another solution for damp installation rooms. The height-adjustable frame construction and conical base are also made of galvanised sheet steel. The resistant outer shell is made of anti-static plastic fabric.

The advantages:

  • Flexible height adjustment from 1.8 to 2.5 metres
  • Available in 7 sizes (up to 9 tonnes in volume)
  • Can be installed directly in the boiler room (maintain legal specifications and distances)
  • Long service life thanks to galvanised frame construction and durable, anti-static plastic fabric
  • Ideal for damp installation rooms
  • Super quick installation involving just a few screw connections



Buried and outdoor tanks

For outdoor storage

If there is no space available in the house or basement, the compacted wood granules can also be stored in a plastic tank buried in the garden or installed outside.

Available sizes

Buried tanks are available in several sizes and can be obtained from our partner company GEOplast. You can find more information here!

Benefits

  • Store solution for use outside the building
  • Dry, secure pellet storage regardless of weather
  • Buried tanks with a 6-tonne capacity (on request)
  • Outdoor tank with a 1.7-tonne capacity (on request)

Pellet storage app

Plan pellet storage quickly and easily

Benefits

  • Available free of charge in the app stores
  • For all Apple and Android systems
  • The right storage solution with only a few steps
  • True-to-scale 2D views
  • 3D examples for every storage solution
  • The most essential conversion formulas at a glance
  • Integrated PDF generator
  • Access to Windhager storage room planning document and storage room brochure
  • App does not require an internet connection and can also be used in the basement
  • Personalisation options available


Download the free app here:


Link to the browser version
