BioWIN2

THE pellet boiler



The BioWIN2 from Windhager is THE pellet boiler for long-term, carefree heating. It embodies the know-how and experience gained from four

generations of pellet boilers, which have already completed 1 billion hours of service. Every component of the BioWIN2 is therefore carefully designed and state-of-the-art, making heating with pellets even more convenient, economical and reliable. The best demonstration is that Windhager provides a five-year full guarantee for the boiler, stainless steel burner and ignition element.



A miracle of efficiency BioWIN2 Plus: The BIOWIN2 is also available as a pellet condensing boiler. In addition to its proven benefits, it delivers more heat.

Boiler design

 X

Pellet boiler with automatic pellet loading or manual pellet loading (fuel hopper 107 or 200 kg)

 X

Unlike all other pellet boilers, The BioWIN2 does not need to be serviced annually. It needs servicing only once every two years or at the latest after consumption of 16 tonnes of pellets.

 X

Intuitive touch operation. You can also access the pellet boiler via a smartphone.

 X

Fully automated heating surface cleaning

 X

Thanks to its patented ash-sliding grate that runs in the opposite direction, no residue is left in the pellet boiler. This significantly increases its operating safety and makes it resistant to any fluctuation in the pellet quality

 X

The patented low-wear ignition element runs silently, is robust and requires no maintenance

 X

The innovative stainless steel burner is so clean and efficient that the BioWIN2 Touch is several times better than even the strictest statutory emission limit values.

 X

The ash box is extra large so offers plenty of capacity and this, coupled with the efficient boiler combustion, ensures long emptying intervals.

Cogent to the smallest detail

  • Easy to place and assemble due to split delivery

  • Unique as maintenance only required every two years

  • Easy to use thanks to intuitive touch operation and access via smartphone

  • Increased operational safety and unaffected by fluctuating pellet quality due to the ash slider grate that runs in the opposite direction

  • The patented low-wear ignition element runs silently, is robust and requires no maintenance

  • The innovative stainless steel burner is so clean and efficient that the BioWIN2 is several times better than even the strictest statutory emission limit values

  • Mobile XXL ash box only requires emptying 1-2 times a year

The advantages at a glance

+ Easy to place and assemble due to split delivery





+ Unique as maintenance is required only once every two years

+ Mobile XXL ash box requires emptying only 1-2 times a year

Windhager BioWIN2 - THE pellet boiler

JUST LIKE NATURE:

FITS

IN

ANYWHERE.

More pellet boilers

Need more inspiration? We offer pellet heaters in a wide variety of designs. From the pellet central heating boiler to the components for the pellet storage room. See for yourself!

An overview of our pellet heating systems

Pellet storage

Our experience shows that you can convert from a heating system fuelled by fossil fuels to a BioWIN2 wood pellet boiler in only a matter of days. In the event of an old oil heating system, the oil tank room can be quickly converted into a pellet storage room.

Click here for the pellet storage systems
Any questions?
We are there for you!
Produktanfrage

Comfort when you need it


We have adapted the BioWIN2 pellet boiler to your individual needs. You yourself can decide whether you prefer your pellet boiler to be filled by hand or fully automatically. All our models are available in different versions. The BioWIN2 Exklusiv provides the best possible level of comfort and takes care of almost everything for you.

  Exklusiv Premium Exklusiv-SL Klassik-L Exklusiv-S Klassik
Pellet loading fully automated Fully automated

by hand
(weekly hopper
200 kg)

by hand
(weekly hopper
200 kg)
by hand
(daily use container
107 kg)
by hand
(daily use container
107 kg)
Heating surface cleaning Fully automated Fully automated Fully automated Fully automated Fully automated Fully automated
Ash removal fully automated
(ash box)
fully automated
(ash trap)
fully automated
(ash box)
fully automated
(ash trap)
fully automated
(ash box)
fully automated
(ash trap)
Maintenance interval 1-2x per year < 3 months < 10 days < 10 days < 5 days < 5 days

Technical data

The BioWIN2 is available in a total of 5 performance classes and 6 comfort classes.

Type Unit BW 102 BW 152 BW 212 BW 262 BW 332
Nominal thermal output range kW 3.0 - 10.5 4.3 - 15 6.0 - 21 7.6 - 25.9 9.8 - 32.5
Boiler efficiency at nominal load % 93.2 93.3 93.6 93.3 92.8
Hopper capacity of Klassik/ Exklusiv-S/ Klassik-L/ Exklusiv-SL kg 107/200
Boiler body with crate, W x D x H mm 767 x 812 x 1286
Minimum installation dimensions of boiler body, W x D x H mm 714 x 650 x 1146 714 x 720 x 1146
Fuel hopper with crate suction feed system and/or 107 kg/200 kg, W x D x H mm 660 x 612 x 1611 / 820 x 1015 x 1615
Minimum installation dimensions of fuel hopper suction feed system 107 kg/200 kg, W x D x H mm 584 x 592 x 1471 / 584 x 592 x 1231 / 680 x 936 x 1473
Total weight 1) kg 286 286 308 308 308
Weight of boiler body 1) kg 200 200 221 221 221
Minimum weight of boiler body 1) kg 170 170 191 191 191
Flue gas connection diameter mm 130
Power consumption of boiler, part load/nominal load W 18/34 20/39 23/47 26/53 29/64
Energy efficiency class   A+
